The Marco Reticam 3100 Plus Ultra-Widefield Fundus Camera provides advanced retinal imaging that covers the macula through to the far periphery. Its true-color, non-mydriatic technology ensures clear, accurate representation of the retina for confident diagnosis and efficient patient care. The fully automated operation simplifies image capture with automated alignment, focus, and exposure; minimizing user training and saving time in busy clinical settings.
Click here to view our full image gallery.
FEATURES
-
Ultra-Widefield Imaging
176° single-shot capture with 220° montage capability for comprehensive retinal visualization
Little to no lid/lash obstruction
3mm minimum pupil size -
True-Color Accuracy
LED-based imaging delivers natural, clinically accurate color for confident diagnosis
Maintains uniform clarity across all image fields, including superior and inferior retina -
Patient-First Experience
Non-mydriatic capture with a gentle flash for maximum comfort
No need to touch the patient's head for positioning -
Fully Automated Workflow
Auto-alignment, auto-focus, and auto-capture reduce training time and boost throughput
Ideal for busy practices with varied staff experience -
Space-Saving, Modern Design
Compact, tabletop form factor fits easily into any clinical environment -
Flexible, Scalable Software
Web-based viewer allows multi-station access with no per-license fees
Supports multiple export formats: JPG, PNG, DICOM
SPECIFICATIONS
| Feature | Specification |
| Capture Field | Up to 176° (single image); up to 220° (auto montage) |
| Imaging Type | Non-mydriatic, true-color, ultra-widefield |
| Illumination | Advanced LED with true-color technology |
| Capture Speed | <60 ms per image |
| Auto Functions | Alignment, focus, and exposure |
| Software Tools | Adjust gamma, contrast, brightness, color; measure lesion areas; cup-disc ratio |
| Connectivity | DICOM 3.0, LAN, USB, FTP |
| Integration | Direct PACS connection; real-time LAN data sharing |
| Output | Standard image file formats |
| Power Requirements | AC 100–240V, 50–60Hz (varies by region) |
