The Marco LM-101 Manual Lensmeter is designed to measure soft and hard contact lenses as well as conventional spectacle lenses. It is a compact lensmeter with a full 90‑degree inclination that facilitates the measurement of contact lenses when used in the vertical position.
LM-101 features include prism compensator, external power and axis reading, LED illumination, AC or battery-powered operation, and an American style cross-line target. The oversized lens table permits the measurement of conventional lenses from 30mm to 90mm in diameter. The LM-101 Manual Lensmeter is well suited for both lab or office use.
FEATURES
- Discriminating Optics – Full 90-degree inclination, prism compensator, and American-style cross-line target
- Durability – Incomparable Marco construction quality provides a lensmeter that is built to withstand the daily use and demands of a busy eye care practice
- Versatility – Read hard or soft contact lenses as well as conventional lenses from 24mm through 90mm in diameter
- LED Illumination – Switchable dual color (green/orange) LED illumination system for easy-to-read lens measurements
SPECIFICATIONS
- Type Ocular type; external reading
- Target American Cross-line
- Vertex Power Range: +25 to -25 diopters Step: 0.125 diopters up to ±3 diopters 0.25 diopters beyond ±3 diopters
- Cylindrical Axis Range: 0 to 180 degrees Step: 1 degree
- Prismatic Power Range: 5 prism diopters in field of view (20 prism diopters by prism compensator) Step: 1 prism diopter
- Eyepiece Focusing +5 to -5 diopters
- Diameter of Lenses Accommodated 24 to 90mm
- Lamp AC 100V (LED illumination)
- Target Illumination Switchable Dual color, Green/Orange LED (2V 25mA)
- Power source DC 5V 1.2A (AC adapter 100~240V 50~60Hz 0.5A) 2 Each 1.5V D size battery (included)
- Tilting Angle 0 to 90 degrees General
- Dimensions At 0 degrees: 170mm (W) x 450mm (D) x 224mm (H) At 90 degrees: 170mm (W) x 342mm (D) x 470mm (H)
- Weight Approximately 14 lbs.
- Color/Finish Black
- Standard Accessories 7mm nosepiece, prism compensator
- Optional Accessories Manual marking system (for Lab use), Vinyl dust cover
- Storage Temperature 10C –40C, Humidity 30%–85% Dust-free environment
